Handy Line Temporary Horizontal Lifeline

Name: Karam Handy Line Temporary Horizontal Lifeline
Brand: Karam

The Horizon PN4001N is a portable, compact horizontal lifeline solution designed for quick deployment when safe anchorage is needed across a span.

Model Horizon PN4001N EN 795ATEX

DatasheetSpecifications, standards, care

Test certificate available on request

Specifications

Brand	Karam
Model	Horizon PN4001N
Construction of Rope	7x19 galvanized steel wire rope of dia 6.0mm
Maximum Span Length of Wire Rope	18.0m
System Breaking Strength	24kN
Weight	14.30kg
Warranty	1 year from the date of invoice against any manufacturing defects.
Standards	EN 795:2012 Type C TS 16415:2013 Type C (for up to 2 users), ATEX 2014/34/EU

Key features

Compact, lightweight housing for easy transport
Retractable lifeline enables fast setup and pack-away
Built-in winch mechanism for smooth retraction
Simple, tool-free connection for quick anchorage setup

Applications

Anchorage

Care and replacement

Inspect harnesses, lanyards and connectors before every use. Remove from service any equipment that has arrested a fall, or shows cuts, burns, chemical damage or deformed hardware. Have equipment inspected by a competent person at least every twelve months.
