Udyogi

Facade Access

The SafeAccess for suspension work is an efficient height access system for facade maintenance and cleaning.

DatasheetSpecifications, standards, care

Test certificate available on request

Specifications

Brand	Udyogi

Key features

Aluminium rail 5 kg/m (3.35 lbs/ft)
Powder coated sea air resistant or anodized
Custom-made brackets
The rail can be bended to match buildingfacades or internal structures and slopes up to 70° important slopes
Manual, motorized or battery operated trolleys. Active climbing system for important slopes
Compatible with traversing ladders, rope access technicians, Rope Climber and suspended platforms
Powder coated special RAL colours on request
Distance between brackets 3m (9.84 ft) trolley capacity WLL 400kg (882lbs)
Possibility of custom-made solutions with the Fallprotec’s engineering department

Applications

Construction and steel erection
Telecom and power towers
Ports, shipyards and tank cleaning
Maintenance at height

Care and replacement

Inspect harnesses, lanyards and connectors before every use. Remove from service any equipment that has arrested a fall, or shows cuts, burns, chemical damage or deformed hardware. Have equipment inspected by a competent person at least every twelve months.
