Udyogi

Ultra Duos 7100 LRX

Name: Udyogi Ultra Duos 7100 LRX
Brand: Udyogi

Non- ventilated HDPE safety helmet- universal accessories slot, 3-ribbed shell with 8-point suspension.

EN 397

Colour: White

DatasheetSpecifications, standards, care

Test certificate available on request

Specifications

Brand	Udyogi
Shell	HDPE (High Density Polyethylene)
Ventilation	Non-ventilated
Suspension	8- point plastic suspension
Head adjustment	Ratchet fit
Peak size	22 mm
Accessories slot size	30 mm
Internal vertical clearance for plastic suspension	32 mm
Wearing height for plastic suspension	93 mm
Circumference of Headband	520-600 mm
Cradle width	24.58 mm
Chin strap width	19.85 mm
Weight with Ratchet fit adjustment	420 grams
Standards	EN 397:2012 + A1:2012
Colours	White, Blue

Key features

Shell proprietary injection-moulded durable HDPE compound
3 ribbed on the top of the shell for better impact protection
8-point suspension for better load distribution
Unique R5 ratchet with smooth ratchet knob adjusts the all head sizes
Adjustable chin strap for customized fit and comfort
High quality sweat band provides comfort
Universal slots to accommodate face and hearing protection accessories

Applications

Cement
Automobile
Minning
Construction
Telecom
Service Utility

Care and replacement

Inspect the shell and harness before each use. Replace the helmet after any significant impact, or if the shell is cracked, dented or discoloured. Replace within the service life marked by the manufacturer. Do not paint or apply solvents to the shell.
