Class 1 di-electric glove
The LINEPRO® Electrical Glove range; assures hand protection against serious injuries from electric shock and burn.
EN 60903IEC 60903
DatasheetSpecifications, standards, care
- Test certificate available on request
Specifications
| Brand | Udyogi |
|---|---|
| Model | Class 1 |
| Thickness mm (max) EN 60903 | 1.5 |
| Thickness mm (max) ASTM D120 | 1.52 |
| Length (mm) EN 60903 | 360 |
| Color | Red |
| Proof Test Voltage AC (V) | 10,000 |
| Working Voltage AC (V) | 500 |
| Withstand Test Voltage AC (V) | 20,000 |
| Max Use voltage DC | 11250 V |
| Category | R,C |
| Size Range | 8,9,10,11 |
| Standard/ Approval | EN 60903: 2003/ IEC 60903:2014 ASTM D120-08 |
| Arc Flash Protection class (EN61482-1-2) | APC 2 |
| ATPV Value | 10.6 cal/cm2 |
| Packaging | In opaque UV resistant bags |
Key features
- Made with specially treated high grade natural rubber latex compounds
- Superior anatomical construction results in lower hand fatigue
- Higher flexibility for long duration wear comfort
- Each glove is inspected/tested for electrical insulation
- Produced at an ISO 9001:2015 / ISO 14001:2015 accredited facility
Applications
- Substations and switchyards
- Power generation and distribution
- Panel and MCC maintenance
- Data centres
Care and replacement
Keep arc-rated garments clean and free of flammable contaminants. Retire any garment that is torn or has been exposed to an arc. Store insulating gloves away from sunlight and ozone.
