Karam

Girder and Concrete Steel Anchor

Name: Karam Girder and Concrete Steel Anchor
Brand: Karam

The SA 13 is a reliable, reusable anchorage solution designed for use on solid steel structures, girders, and I-beams.

Model SA13 Type B Anchor EN 795IS 3521AS/NZS 5532ATEX

DatasheetSpecifications, standards, care

Test certificate available on request

Specifications

Brand	Karam
Model	SA13 Type B Anchor
Material	Stainless steel and alloy steel
Minimum Breaking Strength	23kN
Preformed Hole of Dia	21mm to 30mm
Thickness of Structure	Upto 40mm
Net Weight	550gms ± 10gm
Warranty	1 year from the date of invoice against any manufacturing defects.
Standards	Certified to EN 795:2012 Type B, IS 3521(Part 7):2021 SA13 also Certified to AS/NZS 5532:2013, ATEX 2014/34/EU Conforms to ANSI Z359.18-2017 Type A

Key features

Reusable anchorage solution for steel girders and I-beams
Strong alloy steel eye nut with durable stainless steel body
Lightweight design for effortless portability and use
Quick one-hand installation for hassle-free setup
Ensures safe, stable anchorage for enhanced hand protection

Applications

Steel Structure

Care and replacement

Inspect harnesses, lanyards and connectors before every use. Remove from service any equipment that has arrested a fall, or shows cuts, burns, chemical damage or deformed hardware. Have equipment inspected by a competent person at least every twelve months.
