RAEPoint Wireless Infrastructure

Name: Honeywell RAEPoint Wireless Infrastructure
Brand: Honeywell

Once signed in, you may be able to access additional documents for your account.

ATEXIECEX

Specifications

Brand	Honeywell
Product Type	RS232-IP Converter
Weight range	3.5 g / 7.7 lbs
Overall Width	201 mm / 7.9 in
Overall Height	4.2 in
Size	L: 10.1 in W: 7.9 in H: 4.2 in
Range	1000 ft (300m)
Humidity Range	0 to 95% RH (Non-Condensing)
Analog Inputs Included	12 to 28 VDC
Wireless Enabled	Yes
Wireless Communication	IEEE 802.15.4 ISM Band
Number of Relay Outputs	5 SPDT relays
Mounting	Wall
Minimum Temperature	-20°C / -4°F
Maximum Temperature	131°F / 55°C
Alarm Included	No
Display Type	4 LEDs (Network, Alarm, Communication, Mode)
Display Readout	4 LEDs (Network, Alarm, Communication, Mode)
Relay Included	Yes
Standards	ATEX: Ex II 2G, Ex d ia IIC T6 / Safety: IECEx: Ex d ia IIC T6, Gb / Wireless: FCC Part 15, R&TTE directive (1999/5/EC) / cCSAus: Class I, Division 1 Group A,B,C,D T6
Certifications - Hazloc	Class 1 Division 1 (ATEX Zone 1)
Ingress Protection	IP65
Electrical Connection	2.4 W
Housing Material	Aluminum
Application	Fence Line Monitoring / Oil and Gas Exploration / Worker Exposure Monitoring
Industry	Healthcare
