G-100 Connecting Link
Grade 80 alloy steel load chain, master links, master link assemblies and connecting links, the parts a chain sling is built from.
Model X-015
- Test certificate available on request
Sizes and ratings
9 sizes| Code | WLL (tonnes) | For Grade 100 Chain (mm) |
|---|---|---|
| X-015-06 | 1.4 | 6 |
| X-015-07 | 2.5 | 45846 |
| X-015-10 | 4 | 10 |
| X-015-13 | 6.7 | 13 |
| X-015-16 | 10 | 16 |
| X-015-20 | 16 | 20 |
| X-015-22 | 19 | 22 |
| X-015-26 | 26.5 | 26 |
| X-015-32 | 40 | 32 |
Specifications
| Brand | Yoke |
|---|---|
| Model | X-015 |
| Grade | 100 |
| WLL range | 1.4–40 tonnes |
Applications
- Chain sling assembly
- Steel plants and foundries
- Heavy engineering
- Ports and yards
Care and replacement
Inspect chain link by link for stretch, nicks, gouges, bent links and wear at the bearing points. Remove from service any chain that has stretched or worn beyond the limits its maker gives.
