Electric Trolley (DLET Series)
The DLET Electric Trolley (0.5–10 tons) provides powered travel along I-beams from 58 to 220 mm wide, running at 11 & 21 m/min at 50 Hz.
- Test certificate available on request
Sizes and ratings
7 sizes| Model | Capacity (t) | Speed 50 Hz (m/min) | Motor (kW) |
|---|---|---|---|
| DLET-0.5 | 0.5 | 11 & 21 | 0.4 |
| DLET-01 | 1 | 11 & 21 | 0.4 |
| DLET-02 | 2 | 11 & 21 | 0.4 |
| DLET-03 | 3 | 11 & 21 | 0.75 |
| DLET-05 | 5 | 11 & 21 | 0.75 |
| DLET-7.5 | 7.5 | 11 & 21 | 0.75 |
| DLET-10 | 10 | 11 & 21 | 0.75 |
Specifications
| Brand | Mega |
|---|---|
| Model | DLET |
| Usage/Application | Powered trolley travel along I-beams; with frequency conversion motor |
| Country Of Origin | India Standard |
| Capacity range | 0.5 ton to 10 ton; speed 11&21 m/min (50 Hz)</li |
Applications
- Workshops and maintenance bays
- Erection and shutdowns
- Warehouses
- Pump and motor removal
Care and replacement
Before use, check the hook latch, the load chain for wear and twist, and that the brake holds the load. Have blocks examined by a competent person at the interval the factory rules set.
