Anchor Plate with Corner Bend

Name: Karam Anchor Plate with Corner Bend
Brand: Karam

The Intermediate Anchor Post for Trapezoidal Roof SA 87A(I) is designed for secure installation on trapezoidal roofs using rivets and self-drilled screws.

Model SA87A(C)(90) EN 795AS/NZS 5532

DatasheetSpecifications, standards, care

Test certificate available on request

Specifications

Brand	Karam
Model	SA87A(C)(90)
Material	Stainless Steel 316
Finish	Polished with ED coated
Weight	2.00kg
Breaking Strength	15kN
Warranty	1 year from the date of invoice against any manufacturing defects. For more details on the terms and conditions, click here .
Standards	EN 795:2012 Type C, AS/NZS 5532:2013

Key features

Intermediate Anchor post designed to be fixed on the Trapezoidal Roof with help of rivets and self-drilled screws supplied with anchor posts.
Anchor to be fixed on the roof sheets peak to prevent water clogging.
Centre holes to be fixed on purling by using screw.
It is compatible with pitch from 200.0 mm, 250.0 mm and 300.0 mm on trapezoidal sheets

Applications

Horizontal Lifeline
Rooftops
Work at Height
Fall Protection
Maintenance
Construction

Care and replacement

Inspect harnesses, lanyards and connectors before every use. Remove from service any equipment that has arrested a fall, or shows cuts, burns, chemical damage or deformed hardware. Have equipment inspected by a competent person at least every twelve months.
