Searchzone Sonik™ Ultrasonic Gas Leak Detector
A robust and reliable gas-leak detection device, Searchzone Sonik will efficiently “hear” the loss of containment of any high-pressure gas within its listening zone.
DatasheetSpecifications, standards, care- Test certificate available on request
Specifications
| Brand | Honeywell |
|---|---|
| Warranty | 36 Months from Date of Shipment |
| Alarm Settings | 6 dB Above Background Noise |
| Visual Indicators | Green/Yellow/Red/Blue |
| Vibration | 2 to 60 Hz |
| Weight range | 6.1 kg |
| Dimension | 103 mm dia x 235 x 179 mm |
| Humidity Range | 0 to 100% RH (Condensing) |
| Calibration | Factory Calibrated (No Field Calibration Required) |
| Digital Communication Ports | Bluetooth to Smartphone or Tablet / HART® with Handheld Communicator or Hardwired / Modbus RTU, RS-485 |
| Sensor Mechanism | Sound Pressure Level at Sensor |
| Mounting | Brackets |
| Operating Frequency Range | 18 kHz to 70 kHz |
| Speed of Response | 1 sec |
| Measuring Range | Focus Mode: On-Axis 7m / Standard Mode: 20 m |
| Conduit Entries | (2) 3/4 in NPT / (2) M25 |
| Field of View | Focus Mode): +/- 20 deg / Standard Mode: +/- 90 deg |
| Warm Up Time | Less than 5 min |
| Minimum Temperature | -55°C |
| Storage Temperature | -55 to +75° C |
| Analog Output Signal Current | 4 to 20 mA |
| Power Requirement | 24 VDC |
| Power Consumption | 15W (Below -30°C) / 4W (-30°C and Above) |
| Ingress Protection | IP66/67 |
| NEMA Rating | NEMA 4x |
| Enclosure Material | Stainless Steel 316L |
| Application | Compressors / Exploration Vessels / Metering Skids / Processing Plant / Turbines / Valves / Wellheads |
| Industry | Energy |
Key features
- Bluetooth Connectivity
- Easy and Intuitive Functional Testing
- Inbuilt Diagnostics and Full Operational Logs
- Instrument Status at a Glance
- Simple Installation and Positioning
- Wide Zone Coverage (Standard Mode)
Applications
- Confined space entry
- Oil, gas and petrochemical
- Wastewater and sewage
- Steel and chemical plants
Care and replacement
Keep sensors and filters clean, charge batteries as directed and record bump tests and calibrations.
