SS4 Flame Detector
Electro-optical digital detectors represent leading edge UV and UV/IR technology.
DatasheetSpecifications, standards, care- Test certificate available on request
Specifications
| Brand | Honeywell |
|---|---|
| Warranty | 2 Years from Date of Shipping |
| Weight range | Aluminum: 4 lbs / Stainless Steel: 7.5 lbs |
| Humidity Range | 5 to 98% RH (Non-Condensing) |
| Relay Output Configuration | Fault Relay: NO & NC Contacts / Fire Alarm Relay: NO & NC Contacts, Latching/Non-Latching, Switch Selectable / Fire Verify Relay: NO & NC Contacts, Adjustable Time From 0 to 30 sec / Relay Contact Ratings: 0.5A @120 VAC, 1.0A @24 VDC |
| Mounting | Swivel Bracket Assembly |
| Spectral Sensitivity | Ultraviolet: 185 to 260 Nanometers / Visible: 400 to 700 Nanometers / Wide Band Infrared: 0.7 to 3.5 micrometers |
| Conduit Entries | 3/4 in NPT |
| Field of View | From Cone of Vision: 120 deg / From On Axis: 60 deg |
| Minimum Temperature | -40˚C |
| Ingress Protection | IP66 |
| NEMA Rating | NEMA 4 |
| Enclosure Material | Copper-Free Powder Coated Aluminum |
| Power Requirement | 24 VDC |
| Power Consumption | 68 mA Normal Operation (Relay Version) / 75 mA Alarm Condition (Relay Version) / 95 mA Alarm Condition (Analog Version) |
| Application | Aircraft Hangars / Co-Generation Plants / Gas Compressor Stations / Gas Turbines & Power Plants / Silane and Hydrogen Gas Storage / Warehouses |
Key features
- Multi-Spectrum™: senses ultraviolet, visible and Wide Band Infrared™
- Built-in test for optical “through the lens” testing
- Detects hydrocarbon and non-hydrocarbon based fires
- Wide field-of-view and solar-blind
- Adjustable detector sensitivity
- Microprocessor based algorithms: FirePic™, Snapshot™ and Tri-Mode Plot™
- Wide temperature range of operation
- Compatible with standard approved fire alarm panels
- Explosion-proof housing
- Time programmable alarm verification
Applications
- Confined space entry
- Oil, gas and petrochemical
- Wastewater and sewage
- Steel and chemical plants
Care and replacement
Keep sensors and filters clean, charge batteries as directed and record bump tests and calibrations.
