3.2~20 Ton Single Girder Wire Rope Hoist (DLER Series)
The DLER Single Girder Wire Rope Hoist (3.2–20 tons) features a frequency conversion trolley and double-speed lifting motor with IP55 protection and insulation grade F.
- Test certificate available on request
Sizes and ratings
30 sizes| Model | Capacity (t) | Std Lift (m) | Work Level FEM/ISO |
|---|---|---|---|
| DLER-3.2-6S | 3.2 | 6 | 2m/M5 |
| DLER-3.2-9S | 3.2 | 9 | 2m/M5 |
| DLER-3.2-12S | 3.2 | 12 | 2m/M5 |
| DLER-3.2-15S | 3.2 | 15 | 2m/M5 |
| DLER-3.2-18S | 3.2 | 18 | 2m/M5 |
| DLER-5.0-6S | 5.0 | 6 | 2m/M5 |
| DLER-5.0-9S | 5.0 | 9 | 2m/M5 |
| DLER-5.0-12S | 5.0 | 12 | 2m/M5 |
| DLER-5.0-15S | 5.0 | 15 | 2m/M5 |
| DLER-5.0-18S | 5.0 | 18 | 2m/M5 |
| DLER-10.0-6S | 10.0 | 6 | 2m/M5 |
| DLER-10.0-9S | 10.0 | 9 | 2m/M5 |
| DLER-10.0-12S | 10.0 | 12 | 2m/M5 |
| DLER-10.0-15S | 10.0 | 15 | 2m/M5 |
| DLER-10.0-18S | 10.0 | 18 | 2m/M5 |
| DLER-12.5-6S | 12.5 | 6 | 1AM/M4 |
| DLER-12.5-9S | 12.5 | 9 | 1AM/M4 |
| DLER-12.5-12S | 12.5 | 12 | 1AM/M4 |
| DLER-12.5-15S | 12.5 | 15 | 1AM/M4 |
| DLER-12.5-18S | 12.5 | 18 | 1AM/M4 |
| DLER-16.0-6S | 16.0 | 6 | 2m/M5 |
| DLER-16.0-9S | 16.0 | 9 | 2m/M5 |
| DLER-16.0-12S | 16.0 | 12 | 2m/M5 |
| DLER-16.0-15S | 16.0 | 15 | 2m/M5 |
| DLER-16.0-18S | 16.0 | 18 | 2m/M5 |
| DLER-20.0-6S | 20.0 | 6 | 1AM/M4 |
| DLER-20.0-9S | 20.0 | 9 | 1AM/M4 |
| DLER-20.0-12S | 20.0 | 12 | 1AM/M4 |
| DLER-20.0-15S | 20.0 | 15 | 1AM/M4 |
| DLER-20.0-18S | 20.0 | 18 | 1AM/M4 |
Specifications
| Brand | Mega |
|---|---|
| Model | DLER |
| Usage/Application | Single girder wire rope lifting; hook with safety latch |
| Country Of Origin | India Standard |
| Ambient temperature | 20°C ~ +40°C; motor over temperature protection |
Key features
- 380V/415V/440V/460V/3PH/50Hz; FEM/ISO work levels</li
- Trolley with frequency conversion motor; double speed/frequency conversion lifting motor
- Motor protection grade IP55, insulation grade F
- Electromagnetic disc brake, maintenance-free; overload limiter
- Control voltage 24V/36V/48V/110V; Schneider contactor & inverter
Applications
- Workshops and gantries
- Construction material lifting
- Production lines
- Stores and loading bays
Care and replacement
Test the limit switches, the brake and the pendant before each shift. Have the hoist examined by a competent person at the interval the factory rules set.
