G100 Clevis Shortening Grab Hook
Mega Link Bow Shackles (Omega/anchor type) are forged, quenched and tempered alloy steel shackles with maximum proof load 2.2× WLL and ultimate load 6× WLL.
- Test certificate available on request
Sizes and ratings
17 sizes| Size of Chain (in) | Size of Chain (mm) | W.L.L. (T) | Weight (kg) |
|---|---|---|---|
| 1/4 | 6 | 0.5 | 0.05 |
| 5/16 | 8 | 0.75 | 0.10 |
| 3/8 | 10 | 1 | 0.15 |
| 7/16 | 11 | 1.5 | 0.22 |
| 1/2 | 13 | 2 | 0.36 |
| 5/8 | 16 | 3.25 | 0.63 |
| 3/4 | 19 | 4.75 | 1.23 |
| 7/8 | 22 | 6.5 | 1.79 |
| 1 | 25 | 8.5 | 2.28 |
| 1 1/8 | 29 | 9.5 | 3.75 |
| 1 1/4 | 32 | 12 | 5.31 |
| 1 3/8 | 35 | 13.5 | 7.18 |
| 1 1/2 | 38 | 17 | 8.62 |
| 1 3/4 | 45 | 25 | 15.4 |
| 2 | 51 | 35 | 23.7 |
| 2 1/2 | 63 | 55 | 44.6 |
| 3 | 76 | 85 | 70.0 |
Specifications
| Brand | Mega |
|---|---|
| Usage/Application | Chain shortening, lifting |
| Color | Blue |
| Country Of Origin | India |
| Standard | G100 |
| Material | Forged super alloy steel |
| W.L.L. range | 0.5–85 T |
Key features
- 100% tested at 2.5 times working load limit
- 100% magnaflux crack detection
- Sampling break test for each lot
- Fatigue tested at 1.5 times working load limit for 20000 cycles
- Pins are 100% eddy-current test flaw detection
- Suitable for G100 chain
Applications
- Chain sling assemblies
- Wire rope sling terminations
- Workshop and gantry cranes
- Steel and fabrication shops
Care and replacement
Withdraw a hook that is opened at the throat, twisted, cracked or worn at the saddle, or whose latch no longer closes. Never heat, weld or bend a hook back into shape.
