Forged Open Spelter Wire Rope Socket with Round Pin
Wire rope clamps, thimbles and turnbuckles in galvanised, forged and stainless steel, and the press that crimps the ferrules.
Model 8-734
- Test certificate available on request
Sizes and ratings
10 sizes| Code | WLL (tonnes) | Wire Line Size | Weight (kg) |
|---|---|---|---|
| 8-734-06 | 8 | 0.5 | |
| 8-734-10 | 12 | 0.6 | |
| 8-734-13 | 20 | 1.1 | |
| 8-734-16 | 27 | 13 | 1.8 |
| 8-734-19 | 43 | 14 - 16 | 2.6 |
| 8-734-22 | 55 | 18 - 20 | 4.7 |
| 8-734-26 | 76 | 22 - 23 | 7.4 |
| 8-734-28 | 92 | 24 - 25 | 10.1 |
| 8-734-36 | 136 | 26 - 28 | 14.9 |
| 8-734-38 | 170 | 30 - 32 | 20.7 |
Specifications
| Brand | Yoke |
|---|---|
| Model | 8-734 |
| WLL range | 8–170 tonnes |
Applications
- Wire rope terminations
- Guy lines and fencing
- Marine and outdoor rigging
- Tensioning
Care and replacement
Check clamp nuts for tightness and turnbuckle threads for wear and locking before each use. Replace any fitting that is cracked, bent or corroded.
