G100 Connecting Link (Type 1 – Straight)

Name: Mega G100 Connecting Link (Type 1 – Straight)
Brand: Mega

G100 Connecting Link forged from super alloy steel, providing a secure and reliable chain-to-chain or chain-to-fitting connection for G100 lifting systems.

W.L.L. (T) · Weight (kg)

DatasheetSizes, ratings, specifications Mega brochure

Test certificate available on request

Sizes and ratings

6 sizes

Size (mm)	W.L.L. (T)	Weight (kg)
6	1.4	0.08
8	2.5	0.18
10	4	0.34
13	6.7	0.68
16	10	1.34
20	16	2.05

Specifications

Brand	Mega
Usage/Application	Lifting & Rigging
Country Of Origin	India
Color	Blue
Material	Forged super alloy steel
W.L.L. range	1.4–16 T

Key features

100% tested at 2.5 times working load limit
100% magsaflux crack detection
Sampling break test for each lot
Fatigue tested at 1.5 times working load limit for 20000 cycles
Pinn are 100% eddy-current teat flaw detaction
Suitable for G100 chain

Applications

Chain sling assembly
Steel plants and foundries
Heavy engineering
Ports and yards

Care and replacement

Inspect chain link by link for stretch, nicks, gouges, bent links and wear at the bearing points. Remove from service any chain that has stretched or worn beyond the limits its maker gives.
