Bow Shackles
Mega Link Bow Shackles (Omega/anchor type) are forged, quenched and tempered alloy steel shackles with maximum proof load 2.2× WLL and ultimate load 6× WLL.
- Test certificate available on request
Sizes and ratings
17 sizes| Size of Chain (in) | Size of Chain (mm) | W.L.L. (T) | Weight (kg) |
|---|---|---|---|
| 1/4 | 6 | 0.5 | 0.05 |
| 5/16 | 8 | 0.75 | 0.10 |
| 3/8 | 10 | 1 | 0.15 |
| 7/16 | 11 | 1.5 | 0.22 |
| 1/2 | 13 | 2 | 0.36 |
| 5/8 | 16 | 3.25 | 0.63 |
| 3/4 | 19 | 4.75 | 1.23 |
| 7/8 | 22 | 6.5 | 1.79 |
| 1 | 25 | 8.5 | 2.28 |
| 1 1/8 | 29 | 9.5 | 3.75 |
| 1 1/4 | 32 | 12 | 5.31 |
| 1 3/8 | 35 | 13.5 | 7.18 |
| 1 1/2 | 38 | 17 | 8.62 |
| 1 3/4 | 45 | 25 | 15.4 |
| 2 | 51 | 35 | 23.7 |
| 2 1/2 | 63 | 55 | 44.6 |
| 3 | 76 | 85 | 70.0 |
Specifications
| Brand | Mega |
|---|---|
| Usage/Application | Rigging, lifting, load attachment |
| Color | Silver/Galvanized |
| Country Of Origin | India |
| Standard | G-209 (Screw pin), G-213 (Round pin), G-2130 (Bolt Type) |
| W.L.L. range | 0.5–85 T |
Key features
- Forged Quenched and Tempered, with alloy pin
- Maximum Proof Load is 2.2 times the working Load limit
- Maximum Ultimate Load is 6 times the working Load limit
- G-209 with Screw pin; G-213 with Round pin; G-2130 is Bolt Type
Applications
- Rigging for crane lifts
- Connecting slings to lifting points
- Ports and shipyards
- Construction and erection
Care and replacement
Before each lift, check that the pin is fully screwed home and that the body is not bent, stretched, cracked or worn by more than a tenth of its original section. Replace a shackle whose WLL marking can no longer be read. Never substitute a bolt for the pin.
